3.8 Control Antenna Mode
These screens are only seen if Antenna Comm is turned ON.
This sequence of steps allows a user to adjust the antenna’s
azimuth and elevation manually, restart the antenna, turn Sleep
Mode on/off, turn Instant On Mode on/off, install a new pair of
active satellites, set the latitude and longitude, select the active
satellite system, and update satellite frequency data.
Using the ADCU Interface
54-0161
83
Set sleep on/off?
Yes Next Return
Control antenna?
Enter Next Return
Man control antenna?
Yes Next Return
Restart Antenna?
Yes Next Return
Set instant on/off?
Yes Next Return
ALERT SCREENS
Install satellite?
Yes Next Return
Set Lat/Long?
Yes Next Return
select satellite?
Yes Next Return
Sat frequency Scan?
Yes Next Return
Figure 3-27
Control Antenna Mode
Menu Sequence
