KVH Industries TracVision G6 Technical Manual

3.7 Antenna Status Mode
These screens are only seen if Antenna Comm is turned ON.
This sequence of steps allows a user to scan for system errors,
access antenna type, version, and serial number information,
check the signal and noise levels, indicate the skew angle, and
display the bit error rate.
Using the ADCU Interface
54-0161
81
Get Antenna status?
Enter Next Return
Get system error?
Yes Next Return
Get version?
Yes Next Return
Get serial number?
Yes Next Return
Get Thres/sig level?
Yes Next Return
Get skew angle?
Yes Next Return
ALERT SCREENS
Get bit error rate?
Yes Next Return
Figure 3-25
Antenna Status Mode
Menu Sequence
