KVH Industries TracVision G6 Technical Manual

3.2 Data Display and Accessing
the Main Menu
As soon as the self-test routine is completed, the LCD panel
shows one of five data displays selected in the Display Setup
Mode (described in Section 3.3, “Setup Display Mode” on page 69).
When any of the primary data displays are on screen, the soft
keys allow you to switch between the two installed satellites as
well as enter the Main Menu. The key functions and display
options are as follows:
Using the ADCU Interface
54-0161
65
Enter Main
Menu
Track Installed
Satellite A
Track Installed
Satellite B
Primary Data Displays*
Magnetic Heading
###.#°
Pitch Roll Yaw
#.#° #.#° #.#°
Mag/Hdg Rate/Sec
#.#° #.#°
Lat: ##°
Long: ##°
Tracking <Sat Name>
###.#° ##.#° ####
* Variations on these displays are also presented in Figure 3-9.
Figure 3-4
Soft Key Functions and
Primary Data Displays
