KVH Industries TracVision G6 Technical Manual

3.4 Set Data Outputs Mode
The Set Data Outputs function is used to select several types of
data formats available from the GyroTrac. The message formats
are as follows:
• 1 sine/cosine (either 4-wire or B&G 3-wire)
• 3 serial message formats:
- NMEA 0183
- KVH pitch, roll, and yaw
- Cetrek
• 1 Furuno AD10S
These messages are output to displays and external navigation
systems only if selected via the ADCU. Selection procedures are
presented in the following sections.
54-0161
70
TracVision G6 Technical Manual
Set sine-cos levels?
Yes Next Return
Set serial outputs?
Yes Next Return
Setup data outputs?
Enter Next Return
Set Furuno outputs?
Yes Next Return
ALERT SCREENS
Figure 3-10
Data Outputs Mode
Menu Sequence
For more details about the available
data outputs, refer to
Appendix F,
“GyroTrac Data Outputs” on
page 147.
