TracVision G6 Technical Manual
*** Initializing Rate Bias ***
RF: S,B,V,U,V
A/D: 2134 2034 456
A/D: 2139 2016 425
RF: S,B,H,U,V
A/D: 2125 1992 370
A/D: 2117 2112 384
Gyro Bias: Az = 2118.22, El = 2024.11---------Expected range is 1700-2300
Gyro Uncertainty: Az = 3.00, El = 3.00
*** Limit Switch Search ***
RATE BIAS: PASS--------------------------------PASS is expected
Searching for ECHO_119, Threshold = 1000
+POS: 353.3 22.1 419
RF: S,B,H,U,V
+POS: 59.6 22.1 425
Satellite Found: AZ = 251.2, EL = 22.1, RF = 1373
*** Entering Tracking ***
RF: Freeze #1
RF: Freeze #2
+POS: 350.7 22.0 2667
RF: S,B,V,U,V
+POS: 351.2 22.1 2982
RF: S,B,V,U,V
+POS: 352.0 22.4 2953
RF: S,B,V,U,V
+POS: 352.7 22.6 2821
RF: S,B,V,U,V
*** Network ID Check *** ----------------------Comparing the tracked satellite’s network ID to
+POS: 354.1 22.6 2370 the selected satellite’s network ID
RF: S,B,V,U,V
+POS: 353.9 21.9 2788
RF: S,B,V,U,V
+POS: 354.9 22.5 1819
RF: Y,0x1004 ----------------------------------Indicates positive satellite identification
*** Tracking ECHO_119 ***----------------------Identifies satellite currently tracked
Avg: 22.3 0.0 0.0 0.0 0.0 (TV broadcast image should be available)
RF: S,B,V,U,V
+POS: 354.5 22.1 3116
RF: S,B,V,U,V
+POS: 355.0 22.5 1868
RF: S,B,V,U,V
+POS: 354.0 22.0 2912
RF: S,B,V,U,V
+POS: 354.5 21.9 2114
RF: S,B,V,U,V
+POS: 353.1 21.9 2680
Avg: 22.3 21.8 0.0 0.0 0.0
Saved Sat Pos: AZ = 248.2, EL = 22.0
