5 – Maintenance
This section identifies system components that may be replaced in the
field, details how to replace these components, and lists preventive
maintenance routines.
Contents
5.1 Warranty/Service Information . . . . . . . . . . . . . . . . . . . . .103
5.2 Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . .103
5.3 TracVision G6 Field Replaceable Units . . . . . . . . . . . . .104
5.4 PCB Removal and Replacement . . . . . . . . . . . . . . . . . .106
5.5 Antenna Gyro Assembly . . . . . . . . . . . . . . . . . . . . . . . .109
5.6 Azimuth Limit Switch Assembly . . . . . . . . . . . . . . . . . . .112
5.7 Elevation Motor and Belt Replacement . . . . . . . . . . . . .114
5.8 Antenna LNB Replacement . . . . . . . . . . . . . . . . . . . . . .116
5.9 GyroTrac Replaceable Parts . . . . . . . . . . . . . . . . . . . . .118
5.10 Preparation for Shipment . . . . . . . . . . . . . . . . . . . . . . . .119
