• Power cable to connect the ADCU to ship’s power
(Table 2-2 provides proper gauge and length
specifications)
Cable Length Cable Gauge
to 50 ft (15 m) 14 AWG (1.5 mm
2
)
+50 ft (+15 m) 12 AWG (2.5 mm
2
)
Kitpack Contents
The kitpacks packaged with your antenna unit and GyroTrac
contain various hardware and other materials that will be needed
to complete the TracVision system installation. Ensure that the
kitpacks contain all of the items listed in Tables 2-3 and 2-4.
Part Qty.
3
⁄8-16 x 3" hex screws 4
3
⁄
8 flat washers 8
3
⁄8-16 hex nuts 4
3
⁄8 lock washers 4
3
⁄
8 fiber shoulder washer 8
#10-32 x
5
⁄
8" flat head screws 6
Plastic screw covers 12
Foam seal 1
Tie-wraps 2
Core clamp 1
Part Qty.
#8 fiber washers 10
#8 flat washers 10
#8-32 self-locking nuts 5
#10 flat washers 5
#10 lock washers 5
#10-32 Phillips head screws 5
#8-32 Phillips head screws 5
#8 lock washers 5
#8 Phillips head black screws 5
54-0161
10
TracVision G6 Technical Manual
Table 2-3
Antenna Unit Kitpack Contents
Table 2-4
GyroTrac Kitpack Contents
Table 2-2
Recommended ADCU-to-Ship’s
Power Cable Specifications
