Installing Your Selected Satellites
1. Apply power to the ADCU.
2. Following the startup sequence, press the center
button six times until the “Control Antenna?”
screen appears.
3. Press the
ENTER button to access the Control
Antenna Mode.
4. Press the center button until the “Install Satellite?”
screen appears.
5. Follow the process shown in Figure 2-35 on the
following page to install your selected satellites. At
the end of the process, be sure to press the YES
button to restart the antenna.
Installation
54-0161
47
Section 3, “Using the ADCU
Interface” on page 59 provides
complete details on the use of the
ADCU menus, including complete
antenna control details in
Section 3.8, “Control Antenna
Mode” on page 81.
Figure 2-33
Control Antenna Screen
Figure 2-34
Control Antenna Screen
To Next Page
