9.DRIVE AND DRIVEN PULLEYS
9-9
Mongoose/KXR 250
Remove the oil seal from the movable driven
face.
Measure the clutch lining thickness.
Service Limit: 0.5mm replace if below
INSPECTION
Measure the driven face spring free length.
Service Limit: 131mm replace if below
Check the driven face for wear or damage.
Measure the driven face O.D.
Service Limit: 39.94mm replace if below
Oil Seal
