9.DRIVE AND DRIVEN PULLEYS
9-11
Mongoose/KXR 250
CLUTCH DISASSEMBLY
Remove the circlips and retainer plate to
disassemble the clutch.
CLUTCH / DRIVEN PULLEY ASSEMBLY
Circlip
Retainer Plate
Clutch Lining
Keep grease off the clutch linings.
＊
