Installing Option Units
A-11
7
Load paper.
• Do not load more paper than will fit under the load limits on the paper
guides.
• The paper cassette will hold approximately 500 sheets of paper with a
80 g/m² (21 lb) basis weight, or with a thickness of 0.11 mm.
8
Set the stack of paper so that it is under the clips as shown in the
figure.
9
Insert the paper cassette back in.
Note
Load Limit Load Limit
Clip Clip
To Next Page
