USB Interface
B-5
USB Interface
This printer supports the Hi-Speed USB 2.0/Full-Speed USB 2.0 interface
specifications and interface signals are as follows.
Specifications
Basic specification
Complies with the Hi-Speed USB 2.0/Full-Speed USB 2.0.
Connectors
Printer: B-type receptacle (female) with upstream port
Cable: B-type plug (male)
Cable
Use shielded cable that complies with the Hi-Speed USB 2.0 standards and
not longer than 5 meters (16 feet).
Transfer Mode
High speed (480 Mbps)
Full speed (12 Mbps)
Power Control
Self-power device
Interface Signals
Pin Signal Description
1 Vbus Power supply (+5 V)
2 D- Data transmission
3 D+ Data transmission
4 GND Signal ground
Shell — Shield
Table B-3
