Installing Option Units
A-19
12
If the duplexer is installed, secu
re the power cord to the duplexer
.
T
ake care not to loosen the power cord.
13
If the duplexer is installed, remove the two cut-out portions from the
upper part of the duplexer re
ar cover removed in step 5.
14
Reinstall the duplexer rear cover
.
NO
Duplexer
Rear Cover
192
194
