RS-232C Cable Connection
B-12
With Windows 95/98/Me, make settings as follows:
1
Click on Start button in the Windows 95/98/Me Task Bar and align
the cursor with Settings, then click on Control Panel from among
the items displayed.
2
The control panel folder opens. Double click on System.
3
System Properties opens. Click on the Device Manager tab, then
click on the COM port to be used.
4
Click on Properties button.
5
The Properties sheet is displayed for the selected COM port. Click on
the Port Settings tab and set the port properties.
6
After setting the properties, click OK button.
To Next Page
