Paper Handling
1-27
Selecting the Unit of Measurement
Then, use the following procedure to set the unit of measurement.
1
Press the > key.
2
Press the or key repeatedly until >>Unit appears. The unit of
measurement can be selected between millimeters and inches. The
current unit of measurement is displayed (the default setting is mm).
3
Press the ENTER key. A blinking question mark (?) appears.
4
Select mm or inch using the or key.
5
Press the ENTER key.
Set the dimensions of paper as described in the next section.
Entering the Width and Length
Then, use the following procedure to set the paper size.
>>Unit
mm
>>Unit
? mm
Enter the paper size for X Dimension and Y Dimension as
shown in the figure.
X Dimension
Y Dimension
148 to 216 mm
(5.83 to 8.5 inches)
210 to 356 mm
(8.27 to 14.02 inches)
To Next Page
