2H9
1-5-19
8. Remove the stopper and then remove the
top cover rack-L from the top cover.
Figure 1-5-24
9. Remove four screws from the top cover.
Figure 1-5-25
Top cover
rack-L
Stopper
Top cover
Top cover
Top cover rack-L
Top cover
Screw
Screw
Screw
Screw
