OPERATION GUIDE 1-1
1 Machine Parts
Main Body
Main body parts pertaining to FAX are described below. For information on other
parts, refer to the Operation Guide.
NOTE: Connect modular phone cable to the Line jack. To connect an external
phone, connect modular phone cable to the Telephone Jack.
1 Operation Panel 5 Telephone Jack
2 Original Cover 6 LINE Jack
3 Platen 7 Power Switch
4 Output Tray 8 Document Processor
1
2
3
4
5
6
7
8
