Kyocera FS-1116MFP

Machine Parts
1-2 OPERATION GUIDE
Operation Panel
The following keys and indicators are used to send or receive faxes. For information
on keys and indicators used for another functions, refer to the Operation Guide.
Message Display
FAX Ready Screen
Press [FAX] to use FAX function. FAX indicator turns on and FAX ready screen
appears.
NOTE: Menus or error messages are shown on the Message Display during FAX
operation. For information about error codes or error messages, refer to Warning
Messages on page 7-3.
1 FAX Key and Indicator 10 Start Key
2 W Key 11 One-touch Keys (1 to 12)
3 X Key 12 Shift Key
4 Numeric Keys 13 Quality Key
5 Stop/Clear Key 14 Redial/Pause Key
6 Message Display 15 Brightness Key
7 Menu Key 16 On-Hook Key
8 Cancel Key 17 Directory Key
9 OK Key
/
11
13 15 1612 14 17
1 42 3 5
7 8 9 106
Normal STD.
06/12 20:52
Normal STD.
06/12 20:52
21
3
1 Brightness
2 Quality
3 Date and Time
