Kyocera KM-2020

2C9
2-3-3
Connector Pin No. Signal I/O Description
YC5
Connected
to the front
cover
safety
switch
YC6
Connected
to the fixing
heater M/S
YC7
Connected
to the
optional
paper
feeder
YC8
Connected
to the
drawer
heater*
YC9
Connected
to the
optional
paper
feeder
1 +5 V1 O 5 V DC power supply for FCSSW
2 NC - Not used
3 +5 V3 I 5 V DC power supply
1 H.LIVE O AC power supply for FH-M/S (LIVE)
2 MH.OUT O AC power supply for FH-M
3 MH.OUT O AC power supply for FH-S
1 DH2.LIVE O AC power supply for drawer heater of the paper feeder (LIVE)
2 NC - Not used
3 NC - Not used
4 DH2.OUT O AC power supply for drawer heater of the paper feeder
1 DH1.LIVE O AC power supply for drawer heater (LIVE)
2 NC - Not used
3 NC - Not used
4 DH1.OUT O AC power supply for drawer heater
1 +24 V4 O 24 V DC power supply for paper feeder
2 P.GND - Ground
