Kyocera KM-2020

2C9
1-5-4
Section Jam code Description Conditions
Paper con-
veying
section
Transfer
section
Fixing sec-
tion
Exit sec-
tion
Feedshift
section
Duplex
section
DP
22
23
24
30
40
50
52
60
61
70
Multiple sheets in the
drawer 2* (first paper
feeder)
Multiple sheets in the
drawer 3* (second paper
feeder)
Multiple sheets in the
drawer 4* (third paper
feeder)
Misfeed in registration/
transfer section
Misfeed in the fixing sec-
tion
Misfeed in the exit sec-
tion
Misfeed in the feedshift
section
Misfeed in duplex paper
conveying section*
Misfeed in duplex exit
section*
No original feed*
The registration switch (RSW) does not turn off within 4320
ms of registration switch (RSW) turning on.
The registration switch (RSW) does not turn off within 2482
ms of drawer paper feed clutch 1 (DPFCL1)* turning on.
The drawer feed switch 1 (DFSW1)* does not turn off within
5267 ms of drawer feed switch 1 (DFSW1)* turning on.
The rdrawer feed switch 1 (DFSW1)* does not turn off within
2223 ms of drawer paper feed clutch 2 (DPFCL2)* turning
on.
The drawer feed switch 2 (DFSW2)* does not turn off within
5267 ms of drawer feed switch 2 (DFSW2)* turning on.
The rdrawer feed switch 2 (DFSW2)* does not turn off within
2223 ms of drawer paper feed clutch 3 (DPFCL3)* turning
on.
A signal other than secondary paper feed start is received
when the machine is waiting for secondary paper feed.
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
The exit switch (ESW) does not turn off within 3020 ms of the
registration switch (RSW) turning off.
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
The feedshift switch (FSSW) does not turn on within 5320
ms of feedshift switch (FSSW) turning on.
The feedshift switch (FSSW) does not turn off within 1530
ms of paper switchback.
The feedshift switch (FSSW) does not turn on within 1530
ms of paper switchback.
The duplex paper conveying switch (DUPPCSW)* does not
turn off within 3280 ms of the feedshift switch (FSSW) turn-
ing on.
The duplex paper conveying switch (DUPPCSW)* does not
turn on within 3280 ms of the feedshift switch (FSSW) turn-
ing on.
The duplex paper conveying switch (DUPPCSW)* does not
turn off within 3280 ms of the feedshift switch (FSSW) turn-
ing off.
The registration switch (RSW) does not turn on within 1760
ms of the duplex paper conveying switch (DUPPCSW)* turn-
ing on.
The registration switch (RSW) does not turn off within 1760
ms of the duplex paper conveying switch (DUPPCSW)* turn-
ing off.
During the primary feed of the second original in the single-
sided or double-sided original mode, even if retry operation is
performed five times, primary original feed is not performed.
*: Optional.
