2C9
1-5-5
Section Jam code Description Conditions
DP 71
72
73
74
75
An original jam in the
original conveying sec-
tion 1*
An original size error
jam*
An original jam in the
original conveying sec-
tion 2*
An original jam in the
original conveying sec-
tion 3*
An original jam in the
original switchback sec-
tion*
During the secondary original feed in the single-sided or
double-sided original mode, the DP timing switch (DPTSW)*
does not turn off within 6500 ms of the original conveying
motor (OCM)* turning on.
During the secondary original feed in the single-sided or
double-sided original mode, the DP timing switch (DPTSW)*
does turn off within 750 ms of the original conveying motor
(OCM)* turning on.
During scanning of the second side or reversing of the origi-
nal for ejection in the double-sided original mode, the DP tim-
ing switch (DPTSW)* does not turn off within 6500 ms of the
original conveying motor (OCM)* turning on.
During scanning of the second side or reversing of the origi-
nal for ejection in the double-sided original mode, the DP tim-
ing switch (DPTSW)* does not turn on within 750 ms of the
original conveying motor (OCM)* turning on.
During the switchback operation of an original in the double-
sided original mode, the original switchback switch (OSBSW)
*does not turn on within 1300 ms of the original conveying
motor (OCM)* turning on.
*: Optional.
