Installation
User Guide 1-4
2
The KM USB Port monitor dialog box appears. Confirm the Port name and click
Advanced.... 2
3
The Serial number list appears. Confirm the serial number and click OK.
If the Serial number list is blank, cancel the installation procedure. Turn off the
printing system and return to step 1. 3
That completes the setup of a USB port. Proceed to step 6 on page 1-7. 4
Network Connection
1
The Local or Network Connection dialog box appears. Select Network
Connection and click Next. 5
2
The Locate Your Printer dialog box appears. Select one of the following search
methods: 6
• Type the printer name...: Leave the printer name blank and click Next. All
printing systems available on network servers appear.
• If you have directly typed in the print server name, click Next.
To Next Page
