5-16 OPERATION GUIDE
3 Press or to select the size.
The paper sizes displayed are as shown in the
table below. When selecting Irregular Sizes, carry
out the following procedures. In the case of the
selection of other sizes, proceed to Step 7.
4 Press the OK key.
The Length can be entered after 2 blinks.
5 Press or to enter the Length Size, and the
press the OK key.
3.88 to 11.63(")/98 to 297 (mm): The range in which
setting is possible.
6 Press or to enter the Width Size.
5.88 to 17.00(")/148 to 432 (mm): The range in
which setting is possible.
7 Press the OK key.
The display will return to that of Step 2.
Inch specifications Metric specifications
A3 R B5 E
A4 R B6 R
A4 A6 R
A5 R Hagaki
A6 R Ledger R
B4 R Legal R
B5 E Letter R
B5 Letter
B6 R Statement R
11×15" R Oficio 2
Folio R 11×15" R
Hagaki 8K
8K 16K
16K 16KR
16KR Customized Size
Customized Size
To Next Page
