Troubleshooting
8-12 OPERATION GUIDE
Paper Output Slot
If Paper misfeed in Eject section Remove paper appears and the jam location indicator shown in
the illustration blinks, a paper jam has occurred in the paper output slot. Follow the steps below to clear paper
jams in the paper output slot.
IMPORTANT: The drum section inside the main body is sensitive to scratches and contaminants. When
removing paper, be careful not to touch it or scratch it with your watch, ring, etc.
1 If jammed paper is seen through the paper output
slot, pull it out to remove it.
NOTE: If the paper does happen to tear, remove any
loose scraps from inside the machine.
2 Pull the left cover handle up to open the left cover.
3 Remove the jammed paper without tearing it.
NOTE: If the paper does happen to tear, remove any
loose scraps from inside the machine.
4 Close the left cover.
To Next Page
