Corrective maintenance
D/R - Fin
Tools
• torque screwdriver
• T30 Torx bit
• at plastic tool
Repair kit
G03507
KR loudspeaker 10'' A10 FOCUS/WIDE
×4
S100094
M6×20 Torx
Prerequisite
Grill removed. See Grill (p.100).
Exploded view
For safety reasons, always use the new screws and spare parts provided in the KR.
If no new screws are available, use blue threadlocker.
Use a at tool made of smooth plastic to avoid scratching the ns.
With the at tool, unhook the n clips one by one.
2
1
x4
3 N.m
T30
A10 owner's manual (EN) version 1.1 101
