L-Acoustics A10 User Manual

Rigging system description
The pickup points are compatible with Ø12 mm shackles WLL 1 t (two provided) and CLAMP250.
When using A10-RIGBAR as the main lifting accessory, always implement a secondary safety using available
holes.
One pickup point
safety points
pickup point
Two pickup points
pickup points
safety point
A10-LIFT
A10-LIFT is a rigging element designed to y a radial array of up to three A10 Wide/Focus.
A10-LIFT features two studs that match the lodgings at the front and rear of the enclosure.
studs
28 A10 owner's manual (EN) version 1.1
