Authorized congurations with A10-LIFT
Authorized congurations with A10-LIFT
Safety instructions
Additional safety with A10-LIFT
On each enclosure on which A10-LIFT is secured, secure a DIN580 eye bolt to the dedicated insert to implement
a secondary safety.
Use a shackle and a steel wire rope. Make sure the steel rope is as tensed as possible without bearing the load.
A10-LIFT quantity and position
Use one A10-LIFT for up to three enclosures in the array.
Do not leave more than two adjacent enclosures unsupported.
A10-LIFT pickup point
Select the same pickup point on each A10-LIFT within an array of up to 6 enclosures.
For larger arrays, refer to Radial arrays of 7 enclosures and more (p.140).
Risk of tilting
When using a single motor or a bridle, make sure the array is symmetrical.
When using a third-party bridle, make sure the angle between the two chains does not exceed 60°.
Hybrid congurations
Either A10 Wide, A10 Focus or a combination of both can be used as illustrated.
A10 owner's manual (EN) version 1.1 139
