L-Acoustics A10 - Flying a Radial Array with A10-LIFT

Rigging procedures
Flying a radial array with A10-LIFT
Type of deployment own radial array
one A10-LIFT for three enclosures
LA-SLING2T or a bridle (optional)
Rigging accessories
Ø12 mm shackles WLL 1 t (provided)
Min number of operators 2
Risk of falling objects
Verify that no unattached items remain on the product or assembly.
Additional safety with A10-LIFT
On each enclosure on which A10-LIFT is secured, secure a DIN580 eye bolt to the dedicated insert to implement
a secondary safety.
Use a shackle and a steel wire rope. Make sure the steel rope is as tensed as possible without bearing the load.
A10-LIFT quantity and position
Use one A10-LIFT for up to three enclosures in the array.
Do not leave more than two adjacent enclosures unsupported.
Refer to APPENDIX A: Authorized congurations with A10-LIFT (p.139).
Risk of tilting
When using a single motor or a bridle, make sure the array is symmetrical.
A10 owner's manual (EN) version 1.1 79
