System components
System components
Loudspeaker enclosures
A10 Focus 2-way passive constant curvature WST
®
10° enclosure: 10'' LF+ 2.5'' HF diaphragm
A10 Wide 2-way passive constant curvature WST
®
30° enclosure: 10'' LF+ 2.5'' HF diaphragm
KS21 High power compact subwoofer: 1x21''
Powering and driving system
LA4X / LA8 / LA12X Amplied controller with DSP, preset library and networking capabilities
Refer to the LA4X / LA8 / LA12X user manual for operating instructions.
Loudspeaker cables
SP cables 4-point speakON loudspeaker cables (4mm² gauge)
SP cables come in four sizes: SP.7 (0.7m/2.3ft), SP5 (5m/16.4ft), SP10 (10 m/32.8ft) and
SP25 (25m/82ft)
SP-Y1 breakout cable for two passive enclosures (2.5mm² gauge) provided with a CC4FP adapter
4-point speakON to 2 × 2-point speakON
DO 8-point PA-COM loudspeaker cables (4mm² gauge)
DO cables come in three sizes: DO.7 (0.7m/2.3ft), DO10 (10m/32.8ft) and DO25
(25m/82ft)
DOSUB-LA8 breakout cable for four passive enclosures (4mm² gauge)
8-point PA-COM to 4 × 2-point speakON
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA4X / LA8 / LA12X user manual for detailed instructions about the whole cabling scheme,
including modulation cables and network.
Rigging elements
A10-BUMP Flying frame for vertical deployment of A10
A10-LIFT Rigging element for horizontal deployment of A10
A10-RIGBAR Rigging bar and pullback for A10
A-TILT Rigging element for stacking A15 and A10 onto KS21
A15-BUMP Flying frame for vertical deployment of A15 and KS21
A15-RIGBAR Rigging bar and pullback for A15 and KS21
KS21-OUTRIG Stability bars for KS21
A-MOUNT Pole mount for A15 and A10
X-BAR Rigging bar for 1 enclosure
K2-JACK 4 tilt adjustment screw jacks + bar for K2-CHARIOT
CLAMP250 Clamp certied for 250 kg
LA-SLING2T Lifting chain (DIN EN 818-4) 2-leg , 8 mm
A10 owner's manual (EN) version 1.1 9
