Rigging system description
The rigging arms are tted with yellow safety labels, that are visible when the rigging arm is not in use.
14 pickup points on each side, one front pickup point (F), and one rear pickup point (R), are available for site angle
adjustments. They are compatible with Ø12 mm shackles WLL 1 t (two provided) and CLAMP250.
1 2
3
4
5
6 7 8 9 10
11 12
13
14
1 2
3
4
5
6 7 8 9 10
11 12
13
14
F R
FRONT
A10-BUMP can be used as the main lifting accessory for ying vertical arrays of A10 Wide/Focus with one or two lifting
points.
A10 owner's manual (EN) version 1.1 25
