Inspection and preventive maintenance
A10 Wide/Focus array with A10-LIFT
Shackles (p.59)
the studs are not bent Ball-locking pins (p.60)
Rigging check (p.64)
the front and rear inserts are
not damaged
Runners and corner stops
(p.62)
A10 Wide/Focus with X-BAR and CLAMP250
the wing knobs can be tightened
and loosened by hand
pull up the lever and release it:
the lever returns to its initial position
all screws are tightened
the top inserts are not damaged
A10 owner's manual (EN) version 1.1 55
