4.0 DESCRIPTION OF CONTROLS
SHELVING EQ
In SHELVING mode the two (Blue) buttons at either end give access to
FREQUECY (HIGH & LOW) and GAIN (cut or boost).
GAIN:
GRAPHIC
Pre-EQ gain adjustment with ±20dB range
PARAMETRIC
Pre-EQ gain adjustment with ±20dB range
DYNAMICS
Gain-make-up adjustment for the Compressor.
The GAIN controls associated with the Graphic, Parametric and
Dynamics sections work independently. Their operation should be
thought of as similar to GAIN controls on three separate processing
units, with the purpose of keeping unity gain throughout the unit.
BYPASS:
Provides individual BYPASS of each of the functions. Channel A & B can also be
individually BYPASSED when not linked. Bypass is separate for each of the
processors and its operation should be thought of as similar to bypass switches
on four separate processing units.
The associated LED is lit when a processor is BYPASSED.
FLAT/REF:
FLAT
For the Graphic and Parametric & Filters processors, FLAT resets all EQ gain
settings to zero i.e. flat response on the selected channel(s). A dialogue box
gives option of ESCAPE to cancel or ENTER to confirm.
For the Dynamics processors FLAT resets all settings to factory defaults - see
Section 5.4 and 5.5.
REFERENCE
Used in conjunction with the optional RTA module - see Section 8.0.
In the Home page pressing FLAT displays hardware and software
versions.
UTILITY:
Direct access to the main set-up parameters for the digEQ. Menu items can be
selected using the DATA WHEEL - press the wheel to toggle between Data and
