11.0 SPECIFICATIONS
11.1 DPF3103
PERFORMANCE
Frequency Response 10Hz to 20kHz ±0.5dB
Input impedance 10k ohm balanced, 3 pin XLR-F
Output impedance <10 ohm transformer balanced, 3 pin XLR-M
Max input level +20dBu
Max output level +20dBu
Nominal level 0Bu
Dynamic range Analogue 95dB
Digital 120dB
Total Harmonic Distortion <0.012% between 10Hz & 15kHz @ +4dBu
<0.04% at 20kHz @ +4dBu
Latency time 1.3ms
Input converters 24 bit @ 44.1kHz or 48kHz
Processing 56 bit
GRAPHIC EQUALISER
Centre Frequency (Hz) 20, 25, 31.5, 40, 50, 60, 80, 100, 125, 160,
200, 250, 315, 400, 500, 630, 800, 1k, 1.25k,
1.6k, 2k, 2.5k, 3.15k, 4k, 5k, 6.3k, 8k, 10k,
12.5k, 16k, 20k
Bandwidth 2/3rd octave
Gain ±15dB, 0.5dB resolution
PARAMETRIC EQUALISER
Number of bands 3 per channel
Frequency range (each band) 20Hz to 20kHz, 1/18th octave resolution
Gain -40dB to +15dB, 0.5dB resolution
Bandwidth 1/32 to 2 octaves
HIGH & LOW PASS FILTERS
High pass filter 16Hz to 2kHz, 1/18th octave resolution
Low pass filter 160Hz to 20kHz, 1/18th octave resolution
Response 2nd order Bessel, 2nd order Butterworth or
4th order Linkwitz-Riley
SHELVING EQ
LF shelving 16Hz to 2kHz, 1/18th octave resolution
HF shelving 160Hz to 20kHz, 1/18th octave resolution
Gain ±8dB
COMPRESSOR/LIMITER
Knee Hard or soft
Threshold 0dB to -40dB, 0.5dB resolution
Ratio 1.4:1, 2:1, 3:1, 4:1, 6:1, 8:1, 16:1, LIMIT
Attack time 20µs to 100ms
Release time 20ms to 5s
