9
2.0 INSTALLATION
2.7 INTERNAL LINK OPTION
The outputs on the DPF3130 have power relays for soft switching and automatic
bypass in the event of a power failure. However these relays can be configured, by
way of internal jumpers, to mute the outputs rather than bypass -
Jumper links fitted for power-down BYPASS mode (factory default)
Jumper links fitted for power-down MUTE mode.
