17
4.0 DESCRIPTION OF CONTROLS
RTA
This will only function if the optional Real Time Analyser card is fitted. See
Section 9.
DELAY/RANGE:
DELAY
• Press once to display the DELAY menu. The menu is only shown if the
Delay option is fitted.
RANGE
• Used in conjunction with the optional RTA module. The menu is only
shown if the RTA option is fitted.
ESCAPE:
• Press to abandon a STORE, COMPARE or RECALL command
• Press to move up to the next available page eg. from GRAPHIC equaliser
'fader position' (i.e. top page of GRAPHIC function) to HOME page.
• Press to exit 'Naming a Program' mode.
DATA WHEEL:
The DATA WHEEL has two functions which are selected by pressing the wheel
momentarily and are shown by the two LED's above the wheel.
In general PARAMETER mode moves the cursor around the screen or
menu and DATA mode edits the value selected.
ENTER:
• Press to confirm the Store and Recall commands.
• In the Home page press ENTER to start 'name a program'.
PARAMETER (
):
Used to select parameters for editing in the Dynamics and Utility pages.
KEYBOARD LOCK:
To prevent accidental changes to the current set up of the DPF3103 the
keyboard and DATA wheel can be locked.
• Press and hold ENTER button.
• Pressing the ESCAPE key will toggle the lock on and off. A padlock symbol is
displayed on screen when the keyboard is locked.
