5.0 DESCRIPTION OF MAIN FUNCTIONS
SELECTING CHANNEL A & B:
Channel selection is similar to the Compressor/Limiter, please refer to section
5.4.
LINKING CHANNEL A & B:
Linking is similar to the Compressor/Limiter, please refer to Section 5.4.
SELECTING & ADJUSTING PARAMETERS:
Select the parameter with the
 buttons and adjust each in turn with the
DATA WHEEL. Alternatively you can use the DATA WHEEL to both select
parameters and adjust values.
THRESHOLD
Threshold range is -60dBu to 0dBu
RATIO
Available RATIO's are 1:2, 1:3, 1:4, 1:8, 1:16 and Gate
ATTACK
Attack range is 20µS to 100mS
RELEASE
Release is adjustable from 50mS to 5S
KNEE
Expansion slope can be selected between HARD or SOFT knee.
BYPASS:
BYPASS only affects the Expander/Gate. When bypassed the GR meters do not
operate.
