37
9.0 REAL TIME ANALYSER OPTION
If you wish to name the stored curve do this before STORE. See Section 4.1,
NAMING A PROGRAM for details. The 'RTA Curve' name is shown above the
'Edited Program' name on the HOME page.
When you have named a curve in the HOME page and pressed
ESCAPE you will be returned to the RTA STORE menu. Please note
that the STORE: line does not show the number and name you have
entered. You must press ENTER to confirm the STORE and the new
number and name.
If no name has been entered the system will store the 'Edited Program' name
by default.
RECALL:
The RECALL function is used to re-load any of the 45 stored curves.
• Use the
buttons to select RECALL
• Select the memory number and name using the DATA WHEEL
The memory number is highlighted and the curve name is displayed to the
right of this.
• Press ENTER to confirm
• Press RTA to display the recalled curve.
If the last curve in the Scratch Pad was not saved a 'Current CURVE not
saved' message is displayed. In this case you can either -
• Press the RTA button to cancel RECALL and then STORE the current
CURVE.
OR
• Press ENTER to overwrite the CURVE in the Scratch Pad.
Pressing the RTA or any other FUNCTION button during STORE or
RECALL, rather than ENTER to confirm, cancels the STORE or RECALL
with no change being made.
CORRECTION page
This page superimposes the faders of the GRAPHIC equaliser onto the RTA
display. All functions of the GRAPHIC, see Section 5.1, are available with the
exception of 'Adjusting a band of frequencies'. The actual display and the way
the faders interact with the GRAPHIC depend on whether Channel A, B, or both
have been selected -
CHANNEL A or B
If either Channel A or B is selected then the associated faders are
superimposed onto the RTA display. If the RTA source is Microphone, OutA
or OutB then changes to the GRAPHIC faders will be observed on the
analyser curve.
