11.0 SPECIFICATIONS
EXPANDER/NOISE GATE
Knee Hard or soft
Threshold -60dB to 0dB
Ratio 1:2, 1:3, 1:4, 1:6, 1:8, 1:16, GATE
Attack time 20µs to 100ms
Release 50ms to 5s
INTERFACES
MIDI Program change, SysEx or digEQ NETWORK
POWER
Power requirement 30VA @ 90-250VAC, 50-60Hz
CONNECTORS
Analogue input and output 3 pin XLR-F, pin 2 hot
MIDI input/thru/output 5 pin DIN
PHYSICAL
Dimensions W483mm(19") D230mm(9") H89mm(3.5")
Weight Unit 4.3kg (9.5lbs)
Shipping 5.86kg (12.95lbs)
11.2 DELAY
Units Seconds, Metres, Feet, Samples, Frames
(24fr/s, 25fr/s, 30fr/s or 30 drop frame)
Resolution 0.1ms, 0.01m, 0.1ft, 1 sample
Range 1.3ms to 1.36s
0.45m to 470m
1.5ft to 1,540ft
0.03fr/s to 32fr/s
Temperature compensation 0
o
C to 40
o
C (32
o
F to 104
o
F)
11.3 REAL TIME ANALYSER
Spectrum analysis 31 band, 1/3rd octave, standard EN-61260,
peak or VU
Display mode dBu or dBSPL
Range 20dB or 40dB
Source Microphone, Host input or output
Microphone input Balanced 3 pin XLR-M, adjustable gain,
+15dB phantom power
4 programmable response curves.
Pink Noise Generator Balanced output on 3 pin XLR-M, hi/lo output
level switch
Memories 45 nameable curve locations
