Laars FTCF140 - Page 7

The FT Series Floor Standing, Combination Boiler
Page 7
Model Name FTCF199
Gas Input Rate
MAX 199,000 Btu/h
MIN 19,900 Btu/h
Hot Water Capacity
35
°F Rise 9.88 Gal
45
°F Rise 7.7 Gal
77
°F Rise 4.8 Gal
Installation Indoor / Floor stand type
Flue System Sealed Combustion Direct / Single / Concentric Vent/ SideWall Vent
Vent Run 2"(50ft) , 3"(100ft) Schedule 40 CPVC, PP
Gas Supply Pressure
NG 3.5" WC to 10.5" WC
LP 8.0" WC to 13" WC
Manifold Pressure
Gas Type LP NG
Vent size 2" VENT 3" VENT 2" VENT 3" VENT
FTCF140
Min re
-0.15 " WC -0.216 " WC -0.15 " WC -0.216 " WC
Low re 0.1 " WC 0.079 " WC 0 " WC 0.002 " WC
Power Supply
Main Supply 120V 60Hz / 6A
Maximum Power
Consumption
160W
Ignition System Direct Electronic Ignition / Automatic Flame Sensing
Burner System Single Orice Premixed Fuel Modulation Ceramic Infrared
Gas Valve System Combination modulating (Current proportional)
Minimum Flow Rate 0.5 GPM
Dimensions W15.7” - H53.7” – D26.7”
Shipping Weight 242 lbs ( 110 kg )
Sub Heat Exchanger Water Capacity(DHW) Under 15 Gallon
Main Controller / Control Panel GTX-920CP / P-920C
Water Pressure Min 15 ~ Max 150 PSI
Connection Sizes
Cold Water Inlet / Hot
Water Outlet
3/4" NPT
Space Heating
Supply / Return
1" NPT
Gas Inlet 3/4" NPT
Materials
Casing Cold Rolled Carbon Steel
Heat Exchanger
Primary Heat Exchanger : Stainless Steel
Sub Heat Exchanger : Stainless Steel
Safety Devices
Flame Rod, Overheat Cut O󰀨 Device, Gas Valve Operation
Detector, Exhaust Temperature High Limit Switch, Water
Temperature High Limit Switch
800.900.9276 • Fax 800.559.1583 (Customer Service, Service Advisors)
20 Industrial Way, Rochester, NH 03867 • 603.335.6300 • Fax 603.335.3355 (Applications Engineering)
1869 Sismet Road, Mississauga, Ontario, Canada L4W 1W8 • 905.238.0100 • Fax 905.366.0130
www.Laars.com
Document 4290B
The FT Series, Floor-Standing, Gas Conversion Kit
pg 3 of 4
Manifold pressure
‘NG’ type combustibility ‘LP’ type combustibility
2" VENT 3" VENT 2" VENT 3" VENT
FTCF140
MAX Fire
-0.15
"
WC -0.216
"
WC -0.15
"
WC -0.216
"
WC
MIN Fire
0
”
WC 0.002
”
WC 0.1
”
WC 0.079
”
WC
FTCF199
MAX Fire
-0.134
”
WC -0.173
”
WC
MIN Fire
-0.015
”
WC -0.015
”
WC
Figure D
15.
Setup your combustion analyser and place the sensor
into the combustion test port
16.
Per Table B for Max Fire
,
change dip switch 6 to ON and 7 to OFF.
The unit will cycle up to MAX  re.
17.
WAIT for your combustion analyser to stabilize. This may take up to 3 minutes depending on your combustion
analyser. Then check the CO
2
measurement for MAX  re. Refer to Table D for acceptable MAX  re
combustion readings. At this point, just record the CO
2
readings at MAX Fire. Do NOT attempt to adjust
CO
2
at MAX Fire. ONLY in MIN Fire, so...
18.
Per Table B for MIN Fire
,
change dip switch 6 to OFF and 7 to ON. The unit will cycle down to MIN Fire.
19.
WAIT for your combustion analyser to stabilize. Then check the CO
2
measurement at MIN  re. Refer to
Table D for acceptable MIN  re combustion readings.
20.
If CO
2
readings in Max Fire and MIN  re are acceptable, then skip ahead to Step 23. If not, then open the
Gas Valve Adjustment Port by removing the cap screw with a 4mm Allen wrench. See Figure E.
21.
Then use the 4 mm Allen wrench to make a minor adjustment (1/8 turn) to either increase or decrease CO
2
.
Table B DIP Switch Settings
MBH N/A 140 N/A 199
ON OFF
MIN Fire Normal Operation
MAX Fire Normal Operation
NG Natural LP Propane
3” Vent Size
2” Vent Size
ON OFF ON ON
ON OFF OFF ON
OFF ON ON ON
DO
NOT
CHANGE
REFERENCE
ONLY.
CO
2
value
‘NG’ type combustibility ‘LP’ type combustibility
2" VENT 3" VENT 2" VENT 3" VENT
FTCF140
MAX Fire 8.5~10.5% 9.5~11 %
MIN Fire 8~10% 9~10.5 %
FTCF199
MAX Fire 8.5~10.0% 9.5~11 %
MIN Fire 8~10% 9~10.5 %
Table C
Table D
800.900.9276 • Fax 800.559.1583 (Customer Service, Service Advisors)
20 Industrial Way, Rochester, NH 03867 • 603.335.6300 • Fax 603.335.3355 (Applications Engineering)
1869 Sismet Road, Mississauga, Ontario, Canada L4W 1W8 • 905.238.0100 • Fax 905.366.0130
www.Laars.com
Document 4290B
The FT Series, Floor-Standing, Gas Conversion Kit
pg 3 of 4
Manifold pressure
‘NG’ type combustibility ‘LP’ type combustibility
2" VENT 3" VENT 2" VENT 3" VENT
FTCF140
MAX Fire
-0.15
"
WC -0.216
"
WC -0.15
"
WC -0.216
"
WC
MIN Fire
0
”
WC 0.002
”
WC 0.1
”
WC 0.079
”
WC
FTCF199
MAX Fire
-0.134
”
WC -0.173
”
WC
MIN Fire
-0.015
”
WC -0.015
”
WC
Figure D
15.
Setup your combustion analyser and place the sensor
into the combustion test port
16.
Per Table B for Max Fire
,
change dip switch 6 to ON and 7 to OFF.
The unit will cycle up to MAX  re.
17.
WAIT for your combustion analyser to stabilize. This may take up to 3 minutes depending on your combustion
analyser. Then check the CO
2
measurement for MAX  re. Refer to Table D for acceptable MAX  re
combustion readings. At this point, just record the CO
2
readings at MAX Fire. Do NOT attempt to adjust
CO
2
at MAX Fire. ONLY in MIN Fire, so...
18.
Per Table B for MIN Fire
,
change dip switch 6 to OFF and 7 to ON. The unit will cycle down to MIN Fire.
19.
WAIT for your combustion analyser to stabilize. Then check the CO
2
measurement at MIN  re. Refer to
Table D for acceptable MIN  re combustion readings.
20.
If CO
2
readings in Max Fire and MIN  re are acceptable, then skip ahead to Step 23. If not, then open the
Gas Valve Adjustment Port by removing the cap screw with a 4mm Allen wrench. See Figure E.
21.
Then use the 4 mm Allen wrench to make a minor adjustment (1/8 turn) to either increase or decrease CO
2
.
Table B DIP Switch Settings
MBH N/A 140 N/A 199
ON OFF
MIN Fire Normal Operation
MAX Fire Normal Operation
NG Natural LP Propane
3” Vent Size
2” Vent Size
ON OFF ON ON
ON OFF OFF ON
OFF ON ON ON
DO
NOT
CHANGE
REFERENCE
ONLY.
CO
2
value
‘NG’ type combustibility ‘LP’ type combustibility
2" VENT 3" VENT 2" VENT 3" VENT
FTCF140
MAX Fire 8.5~10.5% 9.5~11 %
MIN Fire 8~10% 9~10.5 %
FTCF199
MAX Fire 8.5~10.0% 9.5~11 %
MIN Fire 8~10% 9~10.5 %
Table C
Table D
Note; The greatest installation di󰀨erence between the FTCF140 and FTCF199, other than general output capability
(BTU’s), is that the air inlet and exhaust vents are opposite. See Section 2.4
