2.5 Product Flow Paths and Characteristics
3
2015-04-16
Operating Mode
Chapter 1. – Product Characteristics
Combination boiler of Heating mode. (Central Heating = CH mode)
Water in the heating pipe is used for space heating.
Gas Inlet
Space Heating
Water Return
Space Heating
Water Supply
Space Heating
Water Supply
Space Heating
Water Supply
Space Heating
Water Supply
Gas Inlet
Space Heating
Water Return
Space Heating
Water Return
Space Heating
Water Return
Note: The
condensate trap
has been hidden
to simplify the
view
2.5.1 Central Heating ow.
Combination Boiler Heating Mode.
Water in the heating pipe is used for space heating.
