The FT Series Floor Standing, Combination Boiler
Page 9
Description Diameter
A Gas Connection 3/4" NPT
B ‘CH supply’ Connection 1" NPT
C ‘CH return’ Connection 1" NPT
D ‘DHW outlet’ Connection 3/4" NPT
E ‘DHW inlet’ Connection 3/4" NPT
F Condensate 1/2" NPT
G Drain 1/2" NPT
FTCF199
53.7" 137 cm
15.7" 40 cm
4.0" 10.4 cm
6.6" 16.9 cm
68 cm
18.9"
2.6"
4.3"
4.3"
5.7"
8.8"
3.7"
12.5"
18.2"
22.5"
26.8"
29.4"
48.3"
17.9"
23.3"
26.7"
19.7"
3.0" 7.6 cm
5.0" 13 cm
A
B
C
D
E
F
G
TOP
SIDE
FRONT
3” O EXHAUST VENT
GAS CONNECTION
HYDRONIC SUPPLY
HYDRONIC RETURN
DHW
CONDENSATE
DRAIN ADAPTER
OUTLET
INLET
DHW
3” O AIR INLET
Note: The greatest installation dierence between the
FTCF140 and FTCF199, other than general output
capability (BTU’s), is that the air inlet and exhaust vent
are opposite.
