= pÉêîáÅÉ=j~åì~ä=^MQ_=L=^MU_= m~ÖÉ=S=ENMF=
=
Position Partnumber Description Comment Side
FU1 Variant dependent, see separate list Top
FU2 Variant dependent, see separate list Top
L1 Variant dependent, see separate list Top
NTC1 NTC150KM3_EPC Resistor NTC 150K M3 EPCOS B57045-K154-K Top
NTC2 NTC150KM3_EPC Resistor NTC 150K M3 EPCOS B57045-K154-K Top
P1 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P2 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
Q1 BC549C Transistor bipolar signal BC549C Top
Q2 BC549C Transistor bipolar signal BC549C Top
Q3 BC557B Transistor bipolar signal BC557B Top
Q4 BC557B Transistor bipolar signal BC557B Top
Q5 BC547B Transistor bipolar signal BC547B Top
Q6 MPSA42 Transistor bipolar signal MPSA42 Top
Q7 MPSA42 Transistor bipolar signal MPSA42 Top
Q8 BC557B Transistor bipolar signal BC557B Top
Q9 BC557B Transistor bipolar signal BC557B Top
Q10 BC547B Transistor bipolar signal BC547B Top
Q11 BC557B Transistor bipolar signal BC557B Top
Q12 MPSA42 Transistor bipolar signal MPSA42 Top
Q13 Q6015L5LY Triac Q6015L5 lying Top
Q14 BC557B Transistor bipolar signal BC557B Top
Q15 BC547B Transistor bipolar signal BC547B Top
Q16 BC547B Transistor bipolar signal BC547B Top
Q17 BC547B Transistor bipolar signal BC547B Top
Q18 MPSA92 Transistor bipolar signal MPSA92 Top
Q19 MPSA42 Transistor bipolar signal MPSA42 Top
Q20 MPSA92 Transistor bipolar signal MPSA92 Top
Q21 BC547B Transistor bipolar signal BC547B Top
Q22 BC557B Transistor bipolar signal BC557B Top
Q23 BC547B Transistor bipolar signal BC547B Top
Q24 BC557B Transistor bipolar signal BC557B Top
Q25 BC547B Transistor bipolar signal BC547B Top
Q26 BC557B Transistor bipolar signal BC557B Top
Q27 BC547B Transistor bipolar signal BC547B Top
Q28 BC547B Transistor bipolar signal BC547B Top
Q29 MJE350LY Transistor bipolar power MJE350 lying Top
Q30 MJE350LY Transistor bipolar power MJE350 lying Top
Q31 BD329LY Transistor bipolar power BD329 lying Top
Q32 MJE340LY Transistor bipolar power MJE340 lying Top
Q33 MJE350LY Transistor bipolar power MJE350 lying Top
Q34 MJE340LY Transistor bipolar power MJE340 lying Top
Q35 - Not used Bot.
Q36 Variant dependent, see separate list May have different
value
Bot.
Q37 Variant dependent, see separate list May have different
value
Bot.
Q38 Variant dependent, see separate list May have different
value
Bot.
Q39 - Not used Bot.
Q40 MJL21194_SA Transistor bipolar power MJL21194 surface mounted May have different
value
Bot.
Q41 MJL21194_SA Transistor bipolar power MJL21194 surface mounted May have different
value
Bot.
Q42 Variant dependent, see separate list May have different
value
Bot.
