Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=U=ENUF=
=
`çãéçåÉåí=äáëí=Ñçê=pmUMc^=J=êÉî=MS=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 u47X22.5 Capacitor 470n X2 metallized propylene 22.5mm Top
C2 Variant dependent, see separate list Top
C3 Variant dependent, see separate list Top
C4 u22X22.5 Capacitor 220n X2 metallized propylene 22.5mm Top
C5 Variant dependent, see separate list Top
C6 Variant dependent, see separate list Top
C7 100u50V Capacitor electrolytic 100u 50V 5mm Top
C8A Variant dependent, see separate list Top
C8B Variant dependent, see separate list Top
C8C Variant dependent, see separate list Top
C9A Variant dependent, see separate list Top
C9B Variant dependent, see separate list Top
C9C Variant dependent, see separate list Top
C12 Variant dependent, see separate list Top
C13 Variant dependent, see separate list Top
C14 Variant dependent, see separate list Top
C15 Variant dependent, see separate list Top
C16 22u50V Capacitor electrolytic 22u 50V 5mm Top
C17 2u2100VMMK15 Capacitor polyester 2u2 100V MMK 15mm Top
C18 Variant dependent, see separate list Top
C19 Variant dependent, see separate list Top
C20 100u50V Capacitor electrolytic 100u 50V 5mm Top
C21 Variant dependent, see separate list Top
D1 GBPC35-06 Diode bridge GBPC35-06 Top
D2 BYV26C Diode power switch BYV26C Top
D3 STTA3006PI Diode power STTA3006PI standing Top
D4 STTA3006PI Diode power STTA3006PI standing Top
D5 5V6.4W2% Diode zener 5V6 .4W 2% Top
D6 62V.4W2% Diode zener 62V .4W 2% May have different
value
Top
D7 Variant dependent, see separate list Top
D8 Variant dependent, see separate list Top
FU1 Variant dependent, see separate list Top
JMPR 230V Variant dependent, see separate list Top
JMPR 1 115V Variant dependent, see separate list Top
JMPR 2 115V Variant dependent, see separate list Top
JMPR JB-JC R04M1.2 Resistor jumper 0R 4modules D1.2mm Top
JMPR СP1-СP3 Variant dependent, see separate list Top
JMPR СP2-СP4 Variant dependent, see separate list Top
JMPR СP5-СP6 Variant dependent, see separate list Top
L1 Variant dependent, see separate list Top
L2 Variant dependent, see separate list Top
P1 TBPC3P4M8 Terminal bloc PCB 3pole 4module 8mm2 Top
P2 FCPC5x20-6.3x32 Fuse clip combi PCB 5x20 and 6.3x32 mm fuse
(2pcs)
Top
Q3 BC546 Transistor bipolar signal BC546 Top
Q4 Variant dependent, see separate list Top
R2 1M.7W1% Resistor Metal Film 1M.7W1% Top
R3 33R.25W5% Resistor Carbon Film 33R.25W5% Top
R4 33R.25W5% Resistor Carbon Film 33R.25W5% Top
R5 Variant dependent, see separate list Top
