Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=^MQ_=L=^MU_= m~ÖÉ=R=ENMF=
=
`çãéçåÉåí=äáëí=Ñçê=^MQ_I=^MU_=J=êÉî=MQ^=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 150p100VNP05%5 Capacitor ceramic 150p 100V NP0 5% 5mm Top
C2 470u16V Capacitor electrolytic 470u 16V 5mm Top
C3 47u25V Capacitor electrolytic 47u 25V 5mm Top
C4 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C5 680p400VK20005%5 Capacitor ceramic 680p 400V K2000 5% 5mm Top
C6 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C7 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C8 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C9 2u2100V Capacitor electrolytic 2u2 100V 5mm Top
C10 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C11 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C12 10u50V Capacitor electrolytic 10u 50V 5mm Top
C13 10u50V Capacitor electrolytic 10u 50V 5mm Top
C14 22n250VMMK10 Capacitor polyester 22n 250V MMK 10mm Top
C15 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C16 33n100VMMK5 Capacitor polyester 33n 100V MMK 5mm Top
C17 2u2100V Capacitor electrolytic 2u2 100V 5mm Top
C18 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C19 1n250VMMK5 Capacitor polyester 1n 250V MMK 5mm Top
C20 10u50V Capacitor electrolytic 10u 50V 5mm Top
C21 10u50V Capacitor electrolytic 10u 50V 5mm Top
C22 10u50V Capacitor electrolytic 10u 50V 5mm Top
C23 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C24 39p200VNP05%5 Capacitor ceramic 39p 200V NP0 5% 5mm Top
C25 2u2100VMMK15 Capacitor polyester 2u2 100V MMK 15mm Top
C26 2u2100VMMK15 Capacitor polyester 2u2 100V MMK 15mm Top
D1 15V.4W5% Diode zener 15V .4W 5% Top
D2 1N4148 Diode signal 1N4148 Top
D3 1N4148 Diode signal 1N4148 Top
D4 1N4148 Diode signal 1N4148 Top
D5 1N4148 Diode signal 1N4148 Top
D6 BAV21 Diode signal BAV21 Top
D7 - Not used Top
D8 1N4148 Diode signal 1N4148 Top
D9 1N4148 Diode signal 1N4148 Top
D10 1N4148 Diode signal 1N4148 Top
D11 1N4148 Diode signal 1N4148 Top
D12 1N4148 Diode signal 1N4148 Top
D13 1N4148 Diode signal 1N4148 Top
D14 BAV21 Diode signal BAV21 Top
D15 15V.4W5% Diode zener 15V .4W 5% Top
D16 15V.4W5% Diode zener 15V .4W 5% Top
D17 1N4148 Diode signal 1N4148 Top
D18 1N4148 Diode signal 1N4148 Top
D19 1N4148 Diode signal 1N4148 Top
D20 1N4148 Diode signal 1N4148 Top
D21 BAV21 Diode signal BAV21 Top
D22 1N4004 Diode power 1N4004 Top
D23 1N4004 Diode power 1N4004 Top
D24 1N4004 Diode power 1N4004 Top
D25 1N4004 Diode power 1N4004 Top
D26 Variant dependent, see separate list Top
