= pÉêîáÅÉ=j~åì~ä=ÑmOQMMn= m~ÖÉ=P=EQF=
=
`çãéçåÉåí=äáëí=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment
FAN401 F80x25-24HS Fan 80x80x25mm 24VDC high speed
FAN402 F80x25-24HS Fan 80x80x25mm 24VDC high speed
K401 2K4FUI9330_LAB Trafo. 2,4KW flyback U93/76/30 I93/28/30 core LAB. Rev01
P401 Variant dependent, see separate list
P401A Variant dependent, see separate list
S401 Variant dependent, see separate list
S402 Variant dependent, see separate list
VR1 VR10KLIN31_TOK Potentiometer 10K LIN 31step TOKOS B103 TP96N08 Y4929 Rev1
VR101 VR10KLIN31_TOK Potentiometer 10K LIN 31step TOKOS B103 TP96N08 Y4929 Rev1
VR201 VR10KLIN31_TOK Potentiometer 10K LIN 31step TOKOS B103 TP96N08 Y4929 Rev1
VR301 VR10KLIN31_TOK Potentiometer 10K LIN 31step TOKOS B103 TP96N08 Y4929 Rev1
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position 230V 115V
P401 MLEU3x1.52.5mBLK SJOOW-3xAWG12
P401A - MP5-15P15A125V
S401 RK2-0-10A15x21 -
S402 - RK1-1-6A15x21
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
MLEU3x1.52.5mBLK Mains lead EU Plug type CEE7/VII 3x1.5mm2 2.5m Black
MP5-15P15A125V Mains plug type 5-15P 15A 125V
RK1-1-6A15x21 Switch Rocker Single Pole Double Trough on - on 6A 15x21mm
RK2-0-10A15x21 Switch Rocker Double Pole Single Trough on - off 10A 15x21mm
SJOOW-3xAWG12 Cable SJOOW 3xAWG12 UL style 817
