Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=iaRQ= m~ÖÉ=Q=ERF=
=
`çãéçåÉåí=äáëí=Ñçê=iaRQJQñSJO=J=êÉî=MN=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 4u7100V5x10A Capacitor electrolytic 4u7 100V 5x10mm axial Top
C101 4u7100V5x10A Capacitor electrolytic 4u7 100V 5x10mm axial Top
C201 4u7100V5x10A Capacitor electrolytic 4u7 100V 5x10mm axial Top
C301 4u7100V5x10A Capacitor electrolytic 4u7 100V 5x10mm axial Top
D1 1N4004 Diode power 1N4004 Top
D2 LYEL2.5x5 Diode LED Yellow 2.5x5mm Top
D3 LRED2.5x5 Diode LED Red 2.5x5mm Top
D4 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D5 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D6 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D101 1N4004 Diode power 1N4004 Top
D102 LYEL2.5x5 Diode LED Yellow 2.5x5mm Top
D103 LRED2.5x5 Diode LED Red 2.5x5mm Top
D104 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D105 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D106 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D201 1N4004 Diode power 1N4004 Top
D202 LYEL2.5x5 Diode LED Yellow 2.5x5mm Top
D203 LRED2.5x5 Diode LED Red 2.5x5mm Top
D204 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D205 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D206 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D301 1N4004 Diode power 1N4004 Top
D302 LYEL2.5x5 Diode LED Yellow 2.5x5mm Top
D303 LRED2.5x5 Diode LED Red 2.5x5mm Top
D304 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D305 LGRN2.5x5 Diode LED Green 2.5x5mm Top
D306 LGRN2.5x5 Diode LED Green 2.5x5mm Top
Q1 MPSA42 Transistor bipolar signal MPSA42 Top
Q2 MPSA42 Transistor bipolar signal MPSA42 Top
Q3 MPSA92 Transistor bipolar signal MPSA92 Top
Q4 BC547B Transistor bipolar signal BC547B Top
Q5 BC547B Transistor bipolar signal BC547B Top
Q6 BC547B Transistor bipolar signal BC547B Top
Q101 MPSA42 Transistor bipolar signal MPSA42 Top
Q102 MPSA42 Transistor bipolar signal MPSA42 Top
Q103 MPSA92 Transistor bipolar signal MPSA92 Top
Q104 BC547B Transistor bipolar signal BC547B Top
Q105 BC547B Transistor bipolar signal BC547B Top
Q106 BC547B Transistor bipolar signal BC547B Top
Q201 MPSA42 Transistor bipolar signal MPSA42 Top
Q202 MPSA42 Transistor bipolar signal MPSA42 Top
Q203 MPSA92 Transistor bipolar signal MPSA92 Top
Q204 BC547B Transistor bipolar signal BC547B Top
Q205 BC547B Transistor bipolar signal BC547B Top
Q206 BC547B Transistor bipolar signal BC547B Top
Q301 MPSA42 Transistor bipolar signal MPSA42 Top
Q302 MPSA42 Transistor bipolar signal MPSA42 Top
Q303 MPSA92 Transistor bipolar signal MPSA92 Top
Q304 BC547B Transistor bipolar signal BC547B Top
Q305 BC547B Transistor bipolar signal BC547B Top
Q306 BC547B Transistor bipolar signal BC547B Top
