= pÉêîáÅÉ=j~åì~ä=^MQ_=L=^MU_= m~ÖÉ=V=ENMF=
=
Position Partnumber Description Comment Side
R93 10R2W5% Resistor metal film 10R 2W 5% Top
R94 4R75W5% Resistor wirewound 4R7 5W 5% Top
R95 Variant dependent, see separate list Top
R96 R335W10% Resistor wirewound R33 5W 10% Top
R97 R335W10% Resistor wirewound R33 5W 10% Top
R98 Variant dependent, see separate list Top
R99 - Not used Top
R100 Variant dependent, see separate list Top
R101 Variant dependent, see separate list Top
R102 - Not used Top
R103 Variant dependent, see separate list Top
R104 Variant dependent, see separate list Top
R105 Variant dependent, see separate list Top
S1 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
U1 VTL5C4 IC photocoupler VTL5C4 Top
VR1 VR220RLY2X3M Trimpotentiometer 220R lying 2x3modules Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=Ñçê=^MQ_=îÉêëáçåë=J=êÉî=MQ^=
Position A04B-3-2 A04B-4.5-2 A04B-6-2
D26 1N4148 1N4148 1N4148
FU1 T6A3250-5x20 T10A250-5x20 T10A250-5x20
FU2 T6A3250-5x20 T10A250-5x20 T10A250-5x20
L1 1u2HD1.4_LAB 1u2HD1.4_LAB 1u2HD1.4_LAB
Q36 - - -
Q37 - - -
Q38 - - -
Q42 - MJL21194_SA MJL21194_SA
Q45 - MJL21193_SA MJL21193_SA
Q49 - - -
Q50 - - -
Q51 - - -
R70 200K.7W1% 294K.7W1% 294K.7W1%
R72 - - 270K.7W1%
R83 - - -
R85 - - -
R86 - - -
R90 - R335W10% R335W10%
R95 - R335W10% R335W10%
R98 - - -
R100 5K62W5% 5K62W5% 5K62W5%
R101 - - -
R103 - - -
R104 10R2W5% 10R2W5% 10R2W5%
R105 390K.7W1% 390K.7W1% 390K.7W1%
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=Ñçê=^MU_=îÉêëáçåë=J=êÉî=MQ^=
Position A08B-6.5-2 A08B-10-2 A08B-11-2 A08B-13-2
D26 - - - -
FU1 T10A250-5x20 T15A250-5x20 T10A250-5x20 T15A250-5x20
FU2 T10A250-5x20 T15A250-5x20 T10A250-5x20 T15A250-5x20
L1 - - - -
