= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NS=ENUF=
=
Position SP80FB-4x6-2 SP80FB-2x11-2 SP80FB-2x13-2 SP80FB-2x17-2 SP80FB-2x32-2
R27 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% R04M.6
R30 56K.7W1% 56K.7W1% 56K.7W1% 56K.7W1% 180K.7W1%
R32 133K.7W1% 88K7.7W1% 169K.7W1% 88K7.7W1% 88K7.7W1%
R33 270K.7W1% - 330K.7W1% - 1K.7W1%
R34 2K2.7W1% 2K2.7W1% 2K2.7W1% 2K2.7W1% 2K4.7W1%
R35 4K7.7W1% 4K7.7W1% 4K7.7W1% 4K7.7W1% 3K3.7W1%
R37 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% 2R2.25W5%
R38 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% 2R2.25W5%
R39 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% 2R2.25W5%
R40 1M.7W1% 1M.7W1% 1M.7W1% 1M.7W1% 1M2.7W1%
R44 470R.25W5% 470R.25W5% 470R.25W5% 470R.25W5% 560R.25W5%
R45 - - - - 698R.7W1%
R46 - - - - 196R.7W1%
R47 - - - - 820R.25W5%
R48 2R22W5%SO5 2R22W5%SO5 2R22W5%SO5 2R22W5%SO5 -
U2A TCET1102G - TCET1102G - R04M.6 (2-4)
U2B - - - - R04M.6 (1-5)
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=Ñçê=NNRs=îÉêëáçåë=J=êÉî=MN^=
Position SP80FB-4x6-2U SP80FB-2x11-2U SP80FB-2x13-2U SP80FB-2x17-2U SP80FB-2x32-2U
C01 - - - - 220n250VMMK15
C1A - - - - -
C1B
1500u200V35x504
TSI
1500u200V35x504
TSI
1500u200V35x504
TSI
1500u200V35x504
TSI
-
C1C - - - - 2200u200V35x55
C2A - - - - -
C2B
1500u200V35x504
TSI
1500u200V35x504
TSI
1500u200V35x504
TSI
1500u200V35x504
TSI -
C2C - - - - 2200u200V35x55
C6 - - - - 1n1250VMKP15
C21 2n2Y10 2n2Y10 2n2Y10 2n2Y10 2n2Y10
C22 2n2Y10 2n2Y10 2n2Y10 2n2Y10 2n2Y10
C24 - - - - 22n1000VMKP22.5
C25 - - - - 22n1000VMKP22.5
C27 100p1600VFKP15 100p1600VFKP15 100p1600VFKP15 100p1600VFKP15 -
D01 - - - - 1N4148
D2 - - - - STTA1512PILY
D15 43V.4W2% 43V.4W2% 39V.4W2% 43V.4W2% 43V.4W2%
D16 - - - - BYM26E
D17 - - - - 1N4148
L1 - - - - 400uHEFD30_LAB
LD01 - - - - LYEL2.5x5LY
LD02 - - - - LGRN2.5x5LY
Q9 R01M.6 (b-c) - R01M.6 (b-c) - BC557B
Q10 - - - - BC547B
R01 - - - - 4K7.7W1%
R1 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 33K9W5%17MSO5
R2 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 -
R3 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 18K9W5%17MSO5 -
R5 - - - - 330R2W5%SO5
