Lab.gruppen fp2400Q User Manual

= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NT=ENUF=
=
Position SP80FB-4x6-2U SP80FB-2x11-2U SP80FB-2x13-2U SP80FB-2x17-2U SP80FB-2x32-2U
R9 1K52W5%SO5 1K52W5%SO5 1K52W5%SO5 1K52W5%SO5 1K3W5%SO5
R19 5K62.7W1% 5K62.7W1% 5K62.7W1% 5K62.7W1% 5K9.7W1%
R23 8K2.7W1% 6K8.7W1% 6K8.7W1% 6K8.7W1% 6K8.7W1%
R27 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% R04M.6
R30 56K.7W1% 56K.7W1% 56K.7W1% 56K.7W1% 180K.7W1%
R32 133K.7W1% 88K7.7W1% 169K.7W1% 88K7.7W1% 88K7.7W1%
R33 270K.7W1% - 330K.7W1% - 1K.7W1%
R34 2K2.7W1% 2K2.7W1% 2K2.7W1% 2K2.7W1% 2K4.7W1%
R35 4K7.7W1% 4K7.7W1% 4K7.7W1% 4K7.7W1% 3K3.7W1%
R37 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% 2R2.25W5%
R38 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% 2R2.25W5%
R39 4R7.25W5% 4R7.25W5% 4R7.25W5% 4R7.25W5% 2R2.25W5%
R40 1M.7W1% 1M.7W1% 1M.7W1% 1M.7W1% 1M2.7W1%
R44 470R.25W5% 470R.25W5% 470R.25W5% 470R.25W5% 560R.25W5%
R45 - - - - 698R.7W1%
R46 - - - - 196R.7W1%
R47 - - - - 820R.25W5%
R48 2R22W5%SO5 2R22W5%SO5 2R22W5%SO5 2R22W5%SO5 -
U2A TCET1102G - TCET1102G - R04M.6 (2-4)
U2B - - - - R04M.6 (1-5)
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
100n400VMMK15 Capacitor polyester 100n 400V MMK 15mm
100p1600VFKP15 Capacitor polypropylene 100p 1600V FKP 15mm
133K.7W1% Resistor Metal Film 133K.7W1%
1500u200V35x504TSI Cap. electrolytic 1500u 200V 35x50mm 4 terminals snap in
169K.7W1% Resistor Metal Film 169K.7W1%
180K.7W1% Resistor Metal Film 180K.7W1%
18K9W5%17MSO5 Resistor wirewound 18K 9W 5% 17modules 5mm stand off
196R.7W1% Resistor Metal Film 196R.7W1%
1K.7W1% Resistor Metal Film 1K.7W1%
1K3W5%SO5 Resistor metal film 1K 3W 5% 5mm stand off
1K52W5%SO5 Resistor metal film 1K5 2W 5% 5mm stand off
1M.7W1% Resistor Metal Film 1M.7W1%
1M2.7W1% Resistor Metal Film 1M2.7W1%
1n1250VMKP15 Capacitor polypropylene 1n 1250V MKP 15mm
1N4148 Diode signal 1N4148
1n5Y10 Capacitor 1n5 Y2 metallized paper 10mm
2200u200V35x55 Capacitor electrolytic 2200u 200V 35x45mm snap in
220n250VMMK15 Capacitor polyester 220n 250V MMK 15mm
220u385V35x55PW Cap. electrolytic 220u 385V 35x55mm printed wiring terminals
22n1000VMKP22.5 Capacitor polypropylene 22n 1000V MKP 22.5mm
270K.7W1% Resistor Metal Film 270K.7W1%
2K2.7W1% Resistor Metal Film 2K2.7W1%
2K4.7W1% Resistor Metal Film 2K4.7W1%
2n2Y10 Capacitor 2n2 Y2 metallized paper 10mm
2R2.25W5% Resistor Carbon Film 2R2.25W5%
2R22W5%SO5 Resistor metal film 2R2 2W 5% 5mm stand off
330K.7W1% Resistor Metal Film 330K.7W1%
