= pÉêîáÅÉ=j~åì~ä=pmUMc^=L=pmUMc_= m~ÖÉ=NU=ENUF=
=
330R2W5%SO5 Resistor metal film 330R 2W 5% 5mm stand off
33K9W5%17MSO5 Resistor wirewound 33K 9W 5% 17modules 5mm stand off
39V.4W2% Diode zener 39V .4W 2%
3K3.7W1% Resistor Metal Film 3K3.7W1%
400uHEFD30_LAB Inductor 400uH EFD30 LAB.GRUPPEN Rev 01
43V.4W2% Diode zener 43V .4W 2%
470R.25W5% Resistor Carbon Film 470R.25W5%
4K7.7W1% Resistor Metal Film 4K7.7W1%
4R7.25W5% Resistor Carbon Film 4R7.25W5%
560R.25W5% Resistor Carbon Film 560R.25W5%
56K.7W1% Resistor Metal Film 56K.7W1%
5K62.7W1% Resistor Metal Film 5K62.7W1%
5K9.7W1% Resistor Metal Film 5K9.7W1%
698R.7W1% Resistor Metal Film 698R.7W1%
6K8.7W1% Resistor Metal Film 6K8.7W1%
820R.25W5% Resistor Carbon Film 820R.25W5%
88K7.7W1% Resistor Metal Film 88K7.7W1%
8K2.7W1% Resistor Metal Film 8K2.7W1%
BC547B Transistor bipolar signal BC547B
BC557B Transistor bipolar signal BC557B
BYM26E Diode power switch BYM26E
LGRN2.5x5LY Diode LED Green 2.5x5mm lying
LYEL2.5x5LY Diode LED Yellow 2.5x5mm lying
R01M.6 (b-c) Resistor jumper 0R 1module D.6mm
R04M.6 Resistor jumper 0R 4modules D.6mm
R04M.6 (1-5) Resistor jumper 0R 4modules D.6mm
R04M.6 (2-4) Resistor jumper 0R 4modules D.6mm
STTA1512PILY Diode power STTA1512PI lying
TCET1102G IC photocoupler TCET1102G
